This TFT liquid crystal display (HW-035N0Z012-01) features a 3.5-inch overall dimension, employing TN (Twisted Nematic) technology to deliver a resolution of 320x480 pixels with a vibrant 262K screen color depth. The display is powered by the ILI9488 driver IC, ensuring efficient and reliable performance.
Designed with a 12 o'clock viewing direction, this LCD is optimized for a comfortable viewing experience. The interface is established through a Microcontroller Unit (MCU), providing seamless integration into various systems. The backlight comprises 6 LEDs, each rated at 20mA, totaling 120mA, contributing to a luminous LCM brightness of 250 cd/m² TYP.
Additionally, this TFT LCD boasts a minimum LCM uniformity of 80%, ensuring consistent and even illumination across the display. With a wide operational temperature range from -20 to +70ºC and a storage temperature range of -30 to +80ºC, this display is suitable for diverse applications, demonstrating resilience in varying environmental conditions.
* It is a Transmissive type color active matrix liquid crystal display (LCD).
* It is composed of a TFT LCD panel, driver IC, FPC, backlight.
* Backlight with different brightness is customized according to your request.
* Capacitive & Resistive touch panel/ Demo board is available for your option.
* Customize LCD Display including lcd backlight, brightness, FPC, interface, touch screen, etc.
* RoHS & REACH compliant.
* If you can't find a suitable one, contact us to get a recommendation.
